Ultra Soft Thermal Pad 3.0W High-Performance Silicone Gap Pads For Electronic Components

Китай Dongguan Ziitek Electronic Materials & Technology Ltd. Сертификаты
Китай Dongguan Ziitek Electronic Materials & Technology Ltd. Сертификаты
Термальная проводная пусковая площадка смотрящ и работающ очень хорошее. Мы не имеем никакую потребность для другой термальной проводной пусковой площадки теперь!

—— Питер Гоольсбы

Я объединил с Зиитек на 2 лет, они обеспечили высококачественные термальные проводные материалы, и доставка во времени, рекомендует их материалы фазового перехода

—— Антонелло Сау

Хорошее качество, хорошее обслуживание. Ваша команда всегда дает нам помощь и разрешать, надежда мы будем хорошим всем временем партнера!

—— Крис Рогерс

Оставьте нам сообщение

Ultra Soft Thermal Pad 3.0W High-Performance Silicone Gap Pads For Electronic Components

Ultra Soft Thermal Pad 3.0W High-Performance Silicone Gap Pads For Electronic Components

Большие изображения :  Ultra Soft Thermal Pad 3.0W High-Performance Silicone Gap Pads For Electronic Components

Подробная информация о продукте:
Место происхождения: Китай
Фирменное наименование: ZIITEK
Сертификация: UL and RoHs
Номер модели: ТИФ500-30-11ES
Оплата и доставка Условия:
Количество мин заказа: 1000 шт.
Цена: Подлежит обсуждению
Упаковывая детали: 1000 шт/мешок
Время доставки: 3-5 дней
Условия оплаты: Т/Т
Поставка способности: 10000/день
Подробное описание продукта
Название продукта: Ультрамягкая термопрокладка 3,0 Вт, высокопроизводительные силиконовые прокладки с зазором для элект Твердость: 12 берег 00
Толщина: 0,25 мм~5,0 ммТ Строительство: Силиконовый эластомер с керамическим наполнением
Цвет: Темно-серый Теплопроводность и композиция: 3.0W/m-K
Постоянное использование температуры: -40 ℃ до 200 ℃ Ключевые слова: Ультрамягкая термопрокладка
Удельный вес: 30,15 г/см приложение: Электронные компоненты

Ultra Soft Thermal Pad 3.0W High-Performance Silicone Gap Pads For Electronic Components



TIF®500-30-11ES Series is a thermal pad specifically designed to tackle the high level cooling challenges and environments sensitive to extreme mechanical stress. It combines higt thermal conductivity with a near-fluid ultimate softness, ensuring perfect filling of the contact interface even under ultra-low mounting pressure,completely eliminating air thermal resistance,and providing superior thermal solutions and physical protection for the most precise and higt heat flux electronic components.



Features:


> High thermal conductivity
> Extremely soft

> Low compression stress effectively protects sensitive components
> Self-adhesive without the need for additional surface adhesives
> Good insulation performance


Applications:



Electronic components, 5G, Aerospace, AI, AIoT, AR/VR/MR/XR, Automotive, Consumer Devices, Datacom, Electric Vehicle, Electronic Products, Energy Storage, Industrial, Lighting Equipment, Medical, Military, Netcom, Panel, Power Electronics, Robot, Servers, Smart Home, Telecom, etc.



Typical Properties of TIF®500-30-11ES Series
Property Value Test method
Color Dark Gray Visual
Construction & Compostion Ceramic filled silicone elastomer ******
Density(g/cm³) 3.15 ASTM D792
Thickness Range(inch/mm) 0.010~0.020 0.030~0.200 ASTM D374
(0.25~0.50) (0.75~5.0)
Hardness 12 Shore 00 12 Shore 00 ASTM 2240
Recommended Operating Temperature -40 to 200℃ ******
Breakdown Voltage(V/mm) ≥5500 ASTM D149
Dielectric Constant 7.0 MHz ASTM D150
Volume Resistivity >1.0X1012 Ohm-meter ASTM D257
Flame rating V-0 UL94 (E331100)
Thermal conductivity 3.0 W/m-K ASTM D5470
3.0 W/m-K ISO22007



Product Specifications
Standard Thickness: 0.010" (0.25 mm)~0.200" (5.00 mm) with increments of 0.010" (0.25 mm)
Standard Size: 16"X 16" (406 mm×406 mm)

Component Codes:
Reinforcement Fabric: FG (Fiberglass).
Coating Options: NS1 (Non-adhesive treatment),
DC1 (Single-sided hardening).
Adhesive Options: A1/A2 (Single-sided/Double-sided adhesive).

The TIF® series is available in custom shapes and various forms.
For other thicknesses or more information, please contact us.
Ultra Soft Thermal Pad 3.0W High-Performance Silicone Gap Pads For Electronic Components 0
Packaging Details & Lead time



The packaging of thermal pad

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized



Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated



Company Profile



Ziitek company is a manufacturer of thermal conductive gap fillers, low melting point thermal interface materials, thermal conductive insulators, thermally conductive tapes, electrically & thermally conductive Interface pads and thermal grease,Thermal Conductive plastic,Silicone Rubber,Silicone Foams,Phase Changing Materials products, with well-equipped testing equipment and strong technical force.



Why Choose us ?



1.Our value message is'' Do it right the First time, total quality control''.

2.Our core competencies is thermal conductive interface materials.

3.Competitive advantage products.

4.Condidentiality agreement Bussiness Secrect Contract.

5.Free sample offer.

6.Quality assurance contract.



FAQ



Q: Are you trading company or manufacturer ?

A: We are manufacturer in China



Q: How long is your delivery time?

A: Generally it is 3-7 work days if the goods are in stock. or it is 7-10 work days if the goods are not in stock, it is according to quantity.



Q: Do you provide samples ? is it free or extra cost?

A: Yes, we could offer samples free of charge.
